Triple display for side views- how to do it?

[Shannon Mason 810297]

I was also pretty sure that to SLI you needed a bridge cable plugged in between the two cards itself for SLI to work together? Many SLI cards (I have one too) have a spot at the top with gold fingers that you just slip a small plug over it and I suppose that goes to another card like it.



Well since FSC, ASv6 app itself and FSReal Time don't use graphics, as you said uses CPU perhaps I could get a matrox 2H/3H and up my FPS possibly, I don't mind using window mode, I prefer that with all my apps anyway and hopefully maybe I could setup a 2nd view without killing my frame rates.

[marcus holmes]

Matrox Triplehead 2 Go + TrackIR is the way to go

I think it would be possible to set up like you have noted with the DualHead, however this will lead to two things.



1) The view using the 2 monitors will yield a split right in the middle of your view.

2) Using both of the outputs from your card will drop you FPS a bit. I noticed when I went from 2 monitors to 3 monitors (using the matrox) I ended up gaining FPS like crazy since I wasn't using two outputs.











Benjamin



Has anyone got a 2monitor setup using the Matrox dualhead2go? I am interested to know if in 3d cockpit with IR Track that you will get the split in the middle (In the way) of the cockpit? Or is their a way to set it up the position of where you are seated in cockpit?

[Joseph Jaster 932528]

You don't even need DH2G to do that, I have FS going across two monitors (in both fullscreen and windowed) by using the nVidia control panel, ATI should have a similar function in the Catalyst Control Centre. For nVidia, open the nVidia Control Panel from the Windows one, under the 'Displays' tab, go to 'Set up Multiple Displays' and select 'One Large Horizontal Desktop' from the list, making sure you put the monitors on the correct side, otherwise it will be backwards, which gets very confusing



Unfortunately, you do get the split right in the middle, but if like me you avoid the 2D cockpit like the plague, you will get used to it; especially if you use TrackIR. Approaches can still be a bit tricky though due to the split, so you have to look slightly to the right or left to get the runway fully on one of the monitors..

[marcus holmes]

Thankyou Joseph

You have a very good point, i forgot about the second output on my graphics card, i will give that a try. You may have just saved me £130, If you are ever in my area i own you a beer

[Benjamin Van Eps 987241]

... Just as a side note, my performance increased quite a bit when I went from 2 monitors (using both outputs from my graphics card) to the Matrox TripleHead 2 Go. When I was running two monitors only - FPS took a big hit. For what ever reason managing two separate monitors versus one really wide resolution take more effort.



I didn't like the seam in the middle. It drove me crazy on final approach. Love my 3H2Go + TrackIR



Keep us posted.



Benjamin.

[marcus holmes]

I am thinking about buying a large widescreen monitor (22") and using that as my main display and then having my standard 19" next to it, maybe that will put the seam more towards the side, but i am unsure how easy that will be to set up without the 3D cockpit looking distorted.

[Garry Morris 920567]

Could be totally wrong here, but I believe the reason that you lose a ton of performance using the dual output on the video card versus a Dual/Triple Head2Go is that with the dual output the vcard has to do two entirely separate renders of the game, essentially doubling the load on the video card, whereas since the Dual/TripleHead2Go mimics a single monitor, the card is only doing one set of renders at a time, albeit at a much wider resolution.

[Benjamin Van Eps 987241]

That's my understanding as well... more or less you have doubled the processing.

It was something that was too tasking for my system. I was relieved when the Matrox kicked it all back down.
